Description

DESCRIPTION





Two turn signal indicators, one right and one left, are standard equipment on all instrument clusters. The turn signal indicators are located near the upper edge of the instrument cluster, the right one is between the speedometer and the tachometer, and the left one is between the speedometer and the minor gauge set.

Each turn signal indicator consists of a stencil-like cutout of the International Control and Display Symbol icon for Turn Warning in the opaque layer of the instrument cluster overlay. The dark outer layer of the overlay prevents these indicators from being clearly visible when they are not illuminated. A green Light Emitting Diode (LED) behind each cutout in the opaque layer of the overlay causes each indicator to appear in green through the translucent outer layer of the overlay when it is illuminated from behind by the LED, which is soldered onto the instrument cluster electronic circuit board.

The turn signal indicators are serviced as a unit with the instrument cluster.
