Instrument Cluster Bezel - Installation

INSTALLATION




1. Install the instrument cluster bezel onto the instrument panel and fully engage the two retainer clips to the instrument panel.

2. Install the screws (2) that secure the instrument cluster bezel to the instrument panel.





3. Install the steering column opening cover.

4. Connect the negative battery cable.
