Installation

INSTALLATION




1. Install the seats into the vehicle and engage the seat back frame hooks (1 and 3) with the footmans loops (2 and 4) in the cab back panel.





2. Install the rear seat bolts (1, 3, and 5) and tighten to 40 Nm (30 ft. lbs.).

3. Install the load floor.
