B229B

B229B-00-PASSIVE ENTRY MODULE (PEM) INTERNAL

For a complete wiring diagram, refer to the Wiring Information. Electrical Diagrams

- When Monitored:
Whenever the module is awake.

- Set Condition:
This code is set immediately if the Passive Entry Module internal self test fails.





VERIFY THAT DIAGNOSTIC TROUBLE CODE (DTC) B229B-00-PASSIVE ENTRY MODULE INTERNAL IS ACTIVE
1. With the scan tool, record and erase the DTCs.
2. Cycle the ignition switch off then back on.
3. With the scan tool, read the DTCs.

Does the DTC B229B-00-PASSIVE ENTRY MODULE INTERNAL reset?

Yes

- Replace the Passive Entry Module.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
