B2207

B2207-OCCUPANT RESTRAINT CONTROLLER INTERNAL 1

- When Monitored:
With the ignition on. The Occupant Restraint Controller (ORC) on board diagnostics continuously performs internal circuit tests.

- Set Condition:
This DTC will set if the ORC identifies an out of range internal circuit.





CHECK FOR SQUIB RELATED DTCS

NOTE: Make sure the battery is fully charged.

1. Turn the ignition on.

NOTE: When this DTC is set, the module self test has discovered an internal fault that cannot be repaired and the module must be replaced regardless of DTC status.

2. With the scan tool, read ORC DTCs.

NOTE: When this code is set active or stored do not erase the codes.

Is there any squib related DTCs present?

Yes

- Diagnose specified squib DTCs before diagnosing this DTC.
- Perform the ORC VERIFICATION TEST. Occupant Restraint Controller (ORC) Verification Test.

No

- WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury.

- WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury.

- Replace the ORC.
- Perform the ORC VERIFICATION TEST. Occupant Restraint Controller (ORC) Verification Test.
