B2208

B2208-OCCUPANT RESTRAINT CONTROLLER INTERNAL 2

For a complete wiring diagram, refer to the Wiring Information.

Theory of Operation
When powered, the Occupant Restraint Controller (ORC) performs an internal self test. The repair of this fault condition does not involve any external circuitry and centers on verifying the integrity of the module's internal circuitry and software validity.
- When Monitored:
The ORC checks the status and validity of the internal operating hardware and software at power up during the initialization process, and continuously through the ignition cycle.

- Set Condition:
This DTC sets when a fault is detected internal to ORC hardware and/or software. Once set, this DTC is latched for the entire power cycle. If the same failure is detected in two consecutive power cycles, this DTC is latched active indefinitely.





Always Perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Restraints System Pre-Diagnostic Procedure.
REPLACE OCCUPANT RESTRAINT CONTROLLER (ORC)
1. Turn the ignition on.
2. With the scan tool, erase and read ORC DTCs.

WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury.

WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to take the proper precautions could result in accidental airbag deployment. Failure to follow these instructions may result in possible serious or fatal injury.

When this code is set, view repair.

Repair

- Replace the Occupant Restraint Controller (ORC).
- Perform the RESTRAINTS SYSTEM VERIFICATION TEST Restraints System Verification Test.
