Front Door Glass - Installation

INSTALLATION





1. Install the mounting clips (2) onto the glass, if necessary.
2. Insert the narrow end of the glass (1) into the door through the opening between the inner and outer panels (3). Then engage the front edge of the glass into the front portion of the glass run weatherstrip before rotating the back edge of the glass rearward into the B-pillar portion of the weatherstrip.





3. Pull the glass upward evenly far enough so it can be verified that the glass is seated into both glass run channels.
4. Push the glass down to seat the clips (2) into regulator lift plates (3 and 4) fully.
5. Pull up on the glass and make sure that it is secure.





6. Install the inner belt molding (3) onto the door and seat fully.
7. Install the door speaker. Speaker - Installation
8. Install the trim panel. Front Door Trim Panel - Installation
