Impact Sensor

Supplemental Restraint System - Cavity A1: Center Sensor Assembly Connector C1:



Supplemental Restraint System - Cavity A3: Center Sensor Assembly Connector C3:



Supplemental Restraint System: Center Sensor Assembly Connector-C2:
