Seat Temperature Switch: Service and Repair
Seat Heater Switch Test/Replacement1. Remove the driver's dashboard lower cover.
2. Disconnect the 10P connector (A) from the seat heater switch (B), and remove the seat heater switch.
3. Check for continuity in each switch position according to the table.
4. If the continuity is not as specified, replace the bulbs (C) or the switch.
