Alignment
Alignment Caster angle:
2WD
1°59' ± 1°
4WD
1°53' ± 1°
Camber angle:
Front:
2WD
-0°40' ± 1°
4WD
-0°30' ± 1°
Rear:
2WD
-0°40' ± 45'
4WD
-0°30' ± 45'
Front toe-in
0 ± 2 mm (0 ± 1/16 inch)
Rear toe-in:
2WD
2 ± 2 mm (1/16 ± 1/16 inch)
4WD
0 ± 2 mm (0 ± 1/16 inch)
