Alternator Brush: Service and Repair
1.
Measure the length of the brush protrusion shown in the illustration, and replace the brush if the measured value is below the limit value.
Limit :
2 mm (0.8 in.) or less
2.
The brush can be removed if the solder of the brush lead wire is removed.
3.
When installing a new brush, insert the brush into the holder, and then solder the lead wire.
