Field Coil: Service and Repair

CLUTCH FIELD COIL
1. Remove the clutch hub and pulley following the procedure given.
2. Install shaft protector tool on the nose opening of the compressor.
3. Install the pulley on the compressor as shown in the illustration. Place the tip of the puller screw on the center dimple of the shaft protector and the jaws of the puller around the back side of the field coil.




4. Tighten the forcing screw with a wrench to pull the coil loose from the compressor front head.
