Front Seat

SEAT BACK FRAME REPLACEMENT

1. Remove the following items.
- Recliner cover.
- Seat back panel.
- Headrest guide.
- Seat back cover.

2. Remove the pad (A) from frame (B).

NOTE:
- Remove the side air bag for replacing side air bag installation seat.
- Before service, be fully aware of precautions and service procedure relevant to air bag.

3. Installation is the reverse of removal.
