Lower Panel Replacement
LOWER PANEL REPLACEMENT 1.
Remove the crash pad side cover.
2.
Remove the fuse box cover (A).
3.
Remove the parking brake lever (C).
4.
After loosening the crash pad lower panel mounting screws, then remove the lower panel (B).
5.
Disconnect the connector (A).
6.
Installation is the reverse of removal.
