Front Door Window Glass: Adjustments

Adjustment

Glass Adjustment

NOTE:
- Check the glass run channel for damage or deterioration, and replace them necessary.

1. Remove the door trim.
2. Remove the door screen.
3. Carefully move the glass (A) until the glass mounting bolt are visible, then loosen them.




4. Check that the glass moves smoothly.
