Window Track: Service and Repair

Removal Procedure
1. Remove the door trim panel. Refer to Trim Panel Replacement - Side Front Door.
2. Remove the water deflector. Refer to Water Deflector Replacement - Door.




3. Remove the bolts that retain the front run channel to the door.
4. Carefully pull the front run channel in order to disengage the run channel from the window weather-strip.
5. Remove the front run channel from the door.
6. Slide the window forward.
7. Remove the bolts that retain the rear run channel to the door.
8. Carefully pull the front run channel in order to disengage the run channel from the window weather-strip.
9. Remove the rear run channel from the door.




Installation Procedure
1. Install the rear run channel to the door.

NOTE: Refer to Fastener Note in Cautions and Notes.

2. Install the bolts that retain the rear run channel to the door.

Tighten
Tighten the bolts to 10 N.m (88 lb in).

3. Slide the window rearward into the rear run channel.
4. Install the front run channel to the door.
5. Install the bolts that retain the front run channel to the door.

Tighten
Tighten the bolts to 10 N.m (88 lb in).

6. Install the water deflector. Refer to Water Deflector Replacement - Door.
7. Install the door trim panel. Refer to Trim Panel Replacement - Side Front Door.
