Ignition Switch: Service and Repair

Removal
1. Disconnect the battery ground cable.
2. Remove the instrument Panel driver lower cover.
3. Remove the steering cowl (3).
- Remove the 7 screws.

4. Remove starter switch (2).
- Disconnect the starter switch connector. Remove the screw (1).

Installation
To install, follow the removal steps in the reverse order.
