Fuel Filter: Locations

1. Fuel Pressure Gauge Fitting
2. Fuel Pressure Gauge
3. Fuel Pressure Gauge Bleed Hose
4. Fuel Injector Rail
5. Fuel rail Feed Pipe
6. Fuel Feed Hose
7. Fuel Return Hose
8. Fuel Filter
9. Fuel Shut-off Adapters
10. Fuel Rail Return Pipe
11. Fuel Pressure Regulator
12. Fuel Injector
