Campaign K100 - Replace Battery Monitor System And SW Update
K100NAS120 APR 2012
THIS SERVICE ACTION IS VALID FOR A LIMITED TIME ONLY AND WILL EXPIRE ON 31 MARCH 2014
SECTION: 100
Service Action: Battery Monitoring System Replacement and Software Enhancement Program
AFFECTED VEHICLE RANGE:
XK (X150) VIN: B32843 - B44940
Model Year: 2010 - 2012
CONDITION SUMMARY:
Situation:
In order to ensure that a limited number of 2010 - 2012 model year XK vehicles are fitted with the very latest software and parts to further enhance the owner's experience of these vehicles, vehicles within the VIN range above require a number of module software updates and, if necessary, new parts.
The control modules requiring updating are:
^ Instrument Cluster (IPK) - to optimize battery performance
^ Infotainment Control Module (ICM) - to optimize battery performance
The component which may require replacement is:
^ Battery Monitoring System (BMS) - to rectify a flat battery / non-start condition
Action:
Retailers are required to 'HOLD' all affected vehicles within their control and refrain from releasing the vehicles for onward distribution and sale pending completion of the rework actions detailed in this bulletin. Affected vehicles in the hands of owners should be repaired at the next available opportunity. At the time of customer appointment, ensure that all outstanding service campaigns for each individual vehicle are identified and allocate sufficient time and resources to complete all campaigns. Refer to the Repair Procedure outlined below.
PARTS
TOOLS
WARRANTY
REPAIR PROCEDURE
