Electronic Brake Control Module: Service and Repair

CAB Location.:

The Controller, Antilock Brake (CAB), is attached to the dash panel inside the passenger compartment, just above the heater/air conditioning plenum housing and aligned with the glove box. The CAB is attached to the dash panel by bolts and nuts that are accessible from the engine compartment, just right of the battery.

On models with air conditioning, it will be necessary to remove the air conditioning fascia panel and ducts for access to the CAB and harness connector.
