Heating and Air Conditioning: Application and ID

A/C Application Table:

CAUTION: Do not use bulbs other than the bulbs listed in the Bulb Application Table. Damage to lamp can result.

Service procedures for most of the lamps in the instrument panel, are located in Electrical, Instrument Panel. Some components have lamps that can only be serviced by an Authorized Service Center (ASC) after the component is removed from the vehicle. Contact local dealer for location of nearest ASC.

Bulb Application
A/C HEATER NOT SERVICED
HEATER NOT SERVICED
