Checking Park/Neutral Position Switch Operation

Tests 1 - 4:




Test 5:





SYMPTOM
CHECKING PARK/NEUTRAL POSITION SWITCH OPERATION

POSSIBLE CAUSES
- Intermittent wiring and connectors
- Backup supply circuit short to voltage
- Transmission range sensor
