End Cover Seals - Installation

INSTALLATION

Special Tools:










1. Install the inner seal into the PTU cover using Installer and Handle.





2. Install the outer seal into the PTU cover using Installer and Handle.





3. Install the side cover.
4. Tighten side cover bolts (1) to 23 Nm (17 ft. lbs.).
5. Install the right halfshaftHalf Shaft - Installation.
