Front Bumper: Testing and Inspection

Removal, Inspection, Replacement




1. Remove fasteners from face and reinforcement while bumper is on work bench.
2. Remove reinforcement and inspect bumper face for damage. Replace as required.
3. Remove foam and inspect foam for damage or deterioration. Replace as required.
4. Inspect reinforcement for damage. Replace as required.
5. Install foam.
6. Install reinforcement.
7. Install fasteners that secure reinforcement to bumper face.


1. Inspect front bumper face for damage and check that front bumper is securely mounted.
2. Inspect front bumper for missing attaching hardware.
