LT230 Transfer Box Service and Overhaul



LT230 Transfer Box Service And Overhaul

The following sections detail the procedures for disassembly, overhaul, and reassembly of the Land Rover LT230 series transfer boxes.

For training purposes, all LT230 series overhaul operations have been integrated into one step-by-step section for each major operation.

While each section describes the process in detail, it should only be used as a general procedure guide. Always refer to the most current information and check for recent Service Bulletins and TIBs applicable to the unit being repaired.

Early LT230T transfer boxes up to serial number 288709E are assembled using gaskets, and in these cases any gasket removed should be replaced with new after thoroughly cleaning each mating surface.
