Camshaft Gear/Sprocket: Specifications

Camshaft Timing Gear Bolts
Use new bolts





First pass: No. 3 camshaft 79 Nm (806 kgf-cm, 58 ft-lbf)





Second pass: No. 4 camshaft 100 Nm (1020 kgf-cm, 74 ft-lbf)





Third pass: No. 1 camshaft 79 Nm (806 kgf-cm, 58 ft-lbf)





Final pass: No. 2 camshaft 100 Nm (1020 kgf-cm, 74 ft-lbf)
