Installation

HEATING / AIR CONDITIONING: REAR AIR CONDITIONING PANEL: INSTALLATION





1. INSTALL NO. 2 AIR CONDITIONING CONTROL ASSEMBLY
(a) Attach the 3 claws to install the air conditioning control.
(b) Install the 3 screws.
2. INSTALL REAR CONSOLE END PANEL SUB-ASSEMBLY
(a) w/ Cool Box:
Install the rear console end panel Installation.
(b) w/o Cool Box:
Install the rear console end panel Installation.
