Crankshaft Main Bearing
Main bearing cap
Step 1
27 Nm (275 kgf-cm, 20 ft-lbf)
Step 2
90°
Uniformly tighten the 10 crankshaft bearing cap bolts
Torque
49 Nm (500 kgf-cm, 36 ft-lbf)
Standard clearance
No. 1 and No. 5
0.017 to 0.033 mm (0.0007 to 0.0013 in.)
Others
0.029 to 0.045 mm (0.0011 to 0.0018 in.)
Maximum clearance
No. 1 and No. 5
0.043 mm (0.0017 in.)
Others
0.055 mm (0.0022 in.)
