Connecting Rod, Engine

Connecting rod journal diameter 52.983-53.003 mm (2.085941-2.086728 inch)
Connecting rod journal maximum taper 0.004 mm (0.0002 inch)
Connecting rod journal maximum out-of-round 0.004 mm (0.0002 inch)
Connecting rod-to-pin clearance-standard 0.004-0.0175 mm (0.000157-0.00689 inch)
Connecting rod-to-pin clearance-service limit 0.35 mm (0.01378 inch)
Connecting rod pin bore diameter 21.9985-22.0025 mm (0.866081-0.866238 inch)
Connecting rod length (center-to-center) 150.7 mm (5.933 inch)
Connecting rod maximum allowed bend 0.038 per 25 mm (0.00150 per 0.9843 inch)
Connecting rod maximum allowed twist 0.050 per 25 mm (0.00197 per 0.9843 inch)





Connecting bolts and rod bearing caps and tighten in three stages.
1: Tighten 25 Nm (18 ft. lbs.)
2: Tighten 45 Nm (33 ft. lbs.)
3: Tighten an additional 90 degrees
