Cruise Control Deactivator Switch




Cruise Control Deactivator Switch









Removal

CAUTION: The cruise control deactivator switch plunger must be manually depressed during removal to prevent damage to the switch.

1. Press down on the brake pedal to provide access to the cruise control deactivator switch plunger.

2. While holding the brake pedal down, push the cruise control deactivator switch plunger into the switch as far as possible, then rotate the switch 45 degrees counterclockwise and remove the cruise control deactivator switch. (The switch will rotate easily with the plunger depressed.)

3. Disconnect the cruise control deactivator switch electrical connector.

Installation

NOTE: The cruise control deactivator switch is self-adjusting and must be installed after the brake booster push rod and the brake pedal have been installed. Do not pull-up or push down on the brake pedal during the installation of the cruise control deactivator switch.

1. Install the cruise control deactivator switch, and rotate clockwise 45 degrees.

2. Connect the cruise control deactivator switch electrical connector.
