Smart Junction Box (SJB) DTC Chart

Glass, Frames and Mechanisms

DTC Charts

Smart Junction Box (SJB) DTC Chart






NOTE: This module utilizes a 5-character DTC followed by a 2-character failure type code. The failure type code provides information about specific fault conditions such as opens or shorts to ground. CMDTCs (Continuous Memory Diagnostic Trouble Codes) have an additional 2-character DTC status code suffix to assist in determining DTC history.
