Catalytic Converter: Service and Repair

Fig.3 (Numbers Indicate Sequence Of Removal):

REMOVAL
1. Drain the engine coolant.
2. Remove components in the order shown in Fig.3

1. Main silencer
2. Presilencer
3. Three way catalytic converter
4. Front exhaust pipe
5. Exhaust manifold insulator
6. Warm-up three way catalytic converter
7. EGR pipe
8. Water hose
9. Exhaust manifold

INSTALLATION
1. Re-install components in reverse order of removal. Use Fig.3 as a reference for assembly.
