Home
>>
Mazda
>>
1996
>>
B3000 4WD V6-3.0L OHV
>>
Repair and Diagnosis
>>
Specifications
>>
Electrical Specifications
>>
Powertrain Management
>>
Engine Control Module
>>
M/T
M/T
��� Powertrain Control Module Terminal (Unit Side):
