Windshield Washer Spray Nozzle: Adjustments
WINDSHIELD WASHER NOZZLE ADJUSTMENT
1.
Insert a needle or an equivalent tool into the spray hole of the windshield washer nozzle, and adjust the nozzle direction as shown.
