Console Removal/Installation
CONSOLE REMOVAL/INSTALLATION1. Disconnect the negative battery cable.
2. Remove the following parts:
1. Decoration panel
2. Front console box mat
3. Indicator panel
4. Front console box
5. Dashboard under cover
6. Side wall
7. Console panel
8. Console cover
3. Remove the screws.
4. Remove the bolts.
5. Disconnect the accessory socket connector and auxiliary jack connector, and keyless antenna connector.
6. Remove the console in the direction of the arrow.
7. Install in the reverse order of removal.
