Advanced Keyless System
KEYLESS RECEIVER INSPECTION [ADVANCED KEYLESS SYSTEM]1. Measure the voltage at the auto light/wiper control module terminals as indicated.
Terminal Voltage Table (Reference):
1. Measure the voltage at the auto light/wiper control module terminals as indicated.
