MECHANICAL [SKYACTIV-D 2.2]

id0110s5000100


Outline

•  For SKYACTIV-D 2.2, the following is performed to lower fuel consumption.
―  Low compression ratio
•  Combustion efficiency by lower compression ratio (14.0) (fuel injector (2pin type))
•  Combustion efficiency by lower compression ratio (14.4) (fuel injector (6pin type))
―  Weight reductions
•  Aluminum alloy cylinder block adopted
•  Exhaust manifold integrated cylinder heads adopted
―  Weight reduction and mechanical resistance loss improvements
•  Piston shape optimized
•  Narrowed down crankshaft journal
•  The SKYACTIV-D 2.2 has adopted an IDEVA for improved ignition stability during cold engine starts. (Fuel injector (2pin type))
•  A maintenance-free design for valve clearance has been achieved with the adoption of the HLA.

Structural View

Fuel injector (2pin type)

ac5wzn00001829

Fuel injector (6pin type)

ac8jjn00000372

Structure

•  Consists of the following parts:

Cylinder head cover
(See CYLINDER HEAD COVER [SKYACTIV-D 2.2].)
Cylinder head
(See CYLINDER HEAD [SKYACTIV-D 2.2].)
Cylinder head gasket
(See CYLINDER HEAD GASKET [SKYACTIV-D 2.2].)
Cylinder block
(See CYLINDER BLOCK [SKYACTIV-D 2.2].)
Crankshaft
(See CRANKSHAFT, MAIN BEARING [SKYACTIV-D 2.2].)
Piston
(See PISTON, PISTON RING, PISTON PIN [SKYACTIV-D 2.2].)
Connecting rod
(See CONNECTING ROD, CONNECTING ROD BEARING [SKYACTIV-D 2.2].)
Engine front cover
(See ENGINE FRONT COVER [SKYACTIV-D 2.2].)
Crankshaft pulley
(See CRANKSHAFT PULLEY [SKYACTIV-D 2.2].)
Drive belt
(See DRIVE BELT [SKYACTIV-D 2.2].)
Valve
(See VALVE, VALVE SPRING, VALVE SEAL, VALVE GUIDE [SKYACTIV-D 2.2].)
IDEVA (fuel injector (2pin type))
(See INTAKE STROKE EGR USING DOUBLE EXHAUST VALVE ACTUATION SYSTEM (IDEVA) [SKYACTIV-D 2.2].)
HLA
(See HYDRAULIC LASH ADJUSTER, ROCKER ARM [SKYACTIV-D 2.2].)
Rocker arm
(See HYDRAULIC LASH ADJUSTER, ROCKER ARM [SKYACTIV-D 2.2].)
Camshaft
(See CAMSHAFT [SKYACTIV-D 2.2].)
OCV (fuel injector (2pin type))
(See OIL CONTROL VALVE (OCV) [SKYACTIV-D 2.2].)
Timing chain
(See TIMING CHAIN, CHAIN TENSIONER [SKYACTIV-D 2.2].)
Balancer unit
(See BALANCER UNIT [SKYACTIV-D 2.2].)
Engine mount
(See ENGINE MOUNT [SKYACTIV-D 2.2].)
