EXHAUST GAS PURIFICATION SYSTEM [SKYACTIV-D 2.2]

id0116e1113400

Purpose, Outline

• Purifies contaminants in the exhaust gas by utilizing chemical reactions.

System diagram

Fuel injector (2pin type)

ac5wzn00001934

Fuel injector (6pin type)

ac8wzn00000197

Structure

• The exhaust gas purification system consists of the following parts:

Part name

Reference

Catalytic converter

(See CATALYTIC CONVERTER [SKYACTIV-D 2.2].)

SCR converter

(See SCR CONVERTER [SKYACTIV-D 2.2].)

Ammonia slip catalyst

Part name	Reference
Catalytic converter	(See CATALYTIC CONVERTER [SKYACTIV-D 2.2].)
SCR converter	(See SCR CONVERTER [SKYACTIV-D 2.2].)
Ammonia slip catalyst	(See SCR CONVERTER [SKYACTIV-D 2.2].)
