ANTENNA FEEDER NO.1 INSPECTION

id092000812400

1.  Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0, SKYACTIV-G 2.5].) (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0, SKYACTIV-G 2.5 (WITHOUT i-stop)].) (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-D 2.2].)

2.  Remove the following parts:

(1)  A-pillar trim (RH) (See A-PILLAR TRIM REMOVAL/INSTALLATION.)

(2)  Decoration panel (See DECORATION PANEL REMOVAL/INSTALLATION.)

(3)  Audio unit (See AUDIO UNIT REMOVAL/INSTALLATION.)

3.  Disconnect antenna feeder No.2.

ac5wzw00002935

4.  Verify that the continuity between antenna feeder No.1 terminals is as indicated in the table.

am6zzw00013519

•  If not as indicated in the table, replace antenna feeder No.1. (See ANTENNA FEEDER NO.1 REMOVAL/INSTALLATION.)

am6zzw00013520
