ANTENNA FEEDER NO.1 INSPECTION

id092000812400

Type-A

1. Disconnect the negative battery terminal. (See NEGATIVE BATTERY TERMINAL DISCONNECTION/CONNECTION.)

2. Remove the following parts:

(1) A-pillar trim (See A-PILLAR TRIM REMOVAL/INSTALLATION.)

(2) Front map light (See FRONT MAP LIGHT REMOVAL/INSTALLATION.)

(3) Sunvisor (See SUNVISOR REMOVAL/INSTALLATION.)

(4) Assist handle (See ASSIST HANDLE REMOVAL/INSTALLATION.)

(5) Front scuff plate (See FRONT SCUFF PLATE REMOVAL/INSTALLATION.)

(6) Driver-side front side trim (See FRONT SIDE TRIM REMOVAL/INSTALLATION.)

(7) Lower decoration panel (See DECORATION PANEL REMOVAL/INSTALLATION.)

(8) Bonnet release lever (See BONNET RELEASE LEVER AND RELEASE CABLE REMOVAL/INSTALLATION.)

(9) Fuel-filler lid opener lever (See FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION.)

(10) Driver-side lower panel (See LOWER PANEL REMOVAL/INSTALLATION.)

(11) Rear scuff plate (See REAR SCUFF PLATE REMOVAL/INSTALLATION.)

(12) B-pillar lower trim (See B-PILLAR LOWER TRIM REMOVAL/INSTALLATION.)

(13) Adjust anchor cover on the front seat belt (See FRONT SEAT BELT REMOVAL/INSTALLATION.)

(14) Upper anchor installation bolt on the front seat belt (See FRONT SEAT BELT REMOVAL/INSTALLATION.)

(15) B-pillar upper trim (See B-PILLAR UPPER TRIM REMOVAL/INSTALLATION.)

(16) Trunk board (See TRUNK BOARD REMOVAL/INSTALLATION.)

(17) Trunk side pocket (See TRUNK SIDE POCKET REMOVAL/INSTALLATION.)

(18) Trunk end trim (See TRUNK END TRIM REMOVAL/INSTALLATION.)

(19) Bass-box (with Bose^®) (See BASS-BOX REMOVAL/INSTALLATION.)

(20) Third-row seat cushion (See THIRD-ROW SEAT CUSHION REMOVAL/INSTALLATION.)

(21) Third-row seat back component (See THIRD-ROW SEAT BACK COMPONENT REMOVAL/INSTALLATION.)

(22) Trunk side trim (See TRUNK SIDE TRIM REMOVAL/INSTALLATION.)

(23) D-pillar trim (See D-PILLAR TRIM REMOVAL/INSTALLATION.)

(24) C-pillar trim (See C-PILLAR TRIM REMOVAL/INSTALLATION.)

(25) Headliner (See HEADLINER REMOVAL/INSTALLATION.)

3. Verify that the continuity between antenna feeder No.1 terminals is as indicated in the table.

ac8wzw00004558

• If not as indicated in the table, replace antenna feeder No.1. (See ANTENNA FEEDER NO.1 REMOVAL/INSTALLATION.)

ac8wzw00004559

Type-B
