FRONT FENDER PANEL REMOVAL/INSTALLATION

id091000801000

1.  Disconnect the negative battery cable.

2.  Remove the following parts:

(1)  Windshield wiper arm and blade (SeeWINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION)

(2)  Side cowl grille (SeeCOWL GRILLE REMOVAL/INSTALLATION)

(3)  Front over fender (SeeOVER FENDER REMOVAL/INSTALLATION)

(4)  Front bumper (SeeFRONT BUMPER REMOVAL/INSTALLATION)

(5)  Front combination lights (SeeFRONT COMBINATION LIGHT REMOVAL/INSTALLATION)

(6)  Sail garnish (SeeSAIL GARNISH REMOVAL/INSTALLATION)

3.  Remove in the order indicated in the table.

ac9uuw00000874

1	Screw
2	Front bumper retainer
3	Bolt A
4	Bolt B
5	Bolt C
6	Bolt D
7	Bolt E
8	Clip
9	Seal plate
10	Front fender panel

4.  Install in the reverse order of removal.
