DTC
B2741
Combined sensor (internal malfunction)
DETECTION CONDITION
• Combined sensor internal malfunction is detected.
POSSIBLE CAUSE
• Combined sensor internal malfunction
DTC B2741[DYNAMIC STABILITY CONTROL (DSC)]
id0402b2803900
|
DTC
|
B2741
|
Combined sensor (internal malfunction)
|
|
|
DETECTION CONDITION
|
• Combined sensor internal malfunction is detected.
|
||
|
POSSIBLE CAUSE
|
• Combined sensor internal malfunction
|
||
|
|||
Diagnostic procedure
|
STEP |
INSPECTION |
ACTION |
|
|---|---|---|---|
|
1
|
VERIFY COMBINED SENSOR MALFUNCTION
• Clear the DTCs from the memory.
• Are the same DTCs present?
|
Yes
|
Replace the combined sensor, then go to the next step.
|
|
No
|
Go to the next step.
|
||
|
2
|
VERIFY THAT NO OTHER DTCS ARE PRESENT
• Are any other DTCs output?
|
Yes
|
Go to the applicable DTC inspection.
|
|
No
|
DTC troubleshooting completed.
|
||
