AR01.30-P-5800BA Remove/Install Cylinder Head

AR01.30-P-5800BA Remove/Install Cylinder Head
ENGINES 112 in MODELS 170, 202, 208, 210, 220
ENGINES 113 in MODELS 211.076 /276, 215.374, 220, 230.474 /475

Shown on model 220 with engine 112

1 Electric fan
2 Fan shroud
3 Poly-V-belt
4 Air cleaner housing
5 Resonance tube
6 Resonance unit
7 Right cylinder head cover
8 Right ignition coils
9 Left cylinder head cover
10 Left ignition coils
11 Generator
12 Chain tensioner
13 Intake manifold
14 Camshaft position sensor
15 Coolant line
16 Camshaft sprockets
17 Camshaft bearing bridges
18 Oil filter housing with oil-water heat exchanger

20 Bolts cylinder head ! timing case cover
21 Cylinder head bolts M11 B141.5
22 Left cylinder head
23 Right cylinder head
24 Left cylinder head gasket
25 Right cylinder head gasket
26 Fitting sleeves
