GF68.05-P-0001A Garage Door Opener, Function

GF68.05-P-0001A Garage Door Opener, Function
- 129, 202, 208, 210 as of 1.6.98, 215, 220 with CODE (231) Garage door opener
- 163 as of 1.9.01, 170 as of 1.6.98
- 203, 230 with CODE (231) Garage door opener up to model year 08/YoM 07

Component Identification:

Garage door opener, function
The garage door opener consists of an adaptive radio remote control with three transmit buttons. With these three buttons: Button 1 garage door opener (A67s1), button 2 garage door opener (A67s2) or button 3 garage door opener (A67s3) it is possible to activate various receivers for the opening and closing system of the doors and gates.

Program remote control
Function requirements:
- Circuit 15R or circuit 15 ON
- Press and hold down button 1 garage door opener (A67s1), button 2 garage door opener (A67s2) or button 3 garage door opener (A67s3).
- The garage door opener indicator lamp (A67e4) starts flashing (1 Hz frequency).
- Continue to hold button 1 garage door opener (A67s1), button 2 garage door opener (A67s2) or button 3 garage door opener (A67s3)and hold garage door opener remote control with transmit button pressed for t < 90 s.
After successful programming the garage door opener indicator lamp (A67e4) flashes rapidly (f = 5.5 Hz) for a duration of approx. 10 s.
- Release the two transmit buttons and program additional transmitters as required.

Time switch-off
In order to save the vehicle battery, the transmitter switches off automatically in the learn-in mode, if programming is not accomplished after approx. 100 seconds.

Transmitter mode
If button 1 garage door opener (A67s1), button 2 garage door opener (A67s2) or button 3 garage door opener (A67s3) is actuated, the signal learned in for this memory space is transmitted activating the associated garage door drive.

The garage door opener signal has a range of at least 15 m.

Erasing
- C. 15 R or c. 15 ON.
- Press button 1 of garage door opener (A67s1) and button 3 of garage door opener (A67s3) simultaneously for approx. 20 s. The garage door opener indicator lamp (A67e4) starts flashing.
- Release button 1 on garage door opener (A67s1) and button 3 on garage door opener (A67s3) when garage door opener indicator lamp (A67e4) is flashing within 10 s after it starts flashing. The existing data of the memory locations is erased.

The memories are erased by actuating the button 1 garage door opener (A67s1) and button 3 garage door opener (A67s3) for longer than 20 ms. Successful erasure of all memory locations is indicated for approx. 10 s by the LED flashing rapidly.
