AN82.70-P-0004PA Retrofit Linguatronic Voice Control System

AN82.70-P-0004PA Retrofit Linguatronic Voice Control System
- MODEL 203.2## 1# up to 23.4.04
- with CODE (852) Complete CTEL preinstallation on console
- with CODE (853) MB standard telephone
- with CODE (854) MB portable CTEL
- with CODE (855) TELE AID
- with CODE (359) TELE AID emergency call system
- with CODE (386) Preinstallation for telephone "Handy", UPCI system
- with CODE (387) Preinstallation for telephone "Handy", UPCI system, USA/Canada
- with CODE (388) "cell phone" telephone, UPCI system
- with subsequent telephone fixed installation or retrofit of cell phone, vehicles up to model refinement

Shown on model 203.2 up to 23.4.04






1 Wiring harness for voice control system
2 Cable harness, fiber optic cable
A Version with MB standard telephone code 853
B Version with complete cell phone preinstallation on console code 852 or MB cell phone code 854
A34/4 Telephone interface
A35/11 Voice control system control unit A35/13 Telephone transmitter/receiver D2B
