GF88.79-P-2004PP Store Outside Mirror Position, Function

GF88.79-P-2004PP Store Outside Mirror Position, Function

- with CODE (275c) Electrically adjustable driver seat, steering column and outside mirrors with memory
- with CODE (242b) Electrically adjustable front passenger seat with memory

Function requirements
- Circuit 15R or 15 ON
- No overvoltage or undervoltage
- Driver's door open

Function
Three positions for the left electrically adjustable and heated outside mirror (M21/1) and right electrically adjustable and heated outside mirror (M21/2) can be stored via the memory function. The left electrically adjustable and heated outside mirror (M21/1) and right electrically adjustable and heated outside mirror (M21/2) are adjusted manually with the light switch module (S1).
For storing an outside mirror position there are three switch positions on the left front door seat adjustment switch group (memory) (S91/2) on the memory location switch 1, 2, 3 (S91/2s14) as well as the memory switch (S91/2s9) required for starting the storage procedure.

Before storage, set memory location switch 1, 2, 3 (S91/2s14) to desired position There are two possibilities for button actuation for storage:
- Hold memory switch (S91/2s9) down and additionally actuate memory location switch 1, 2, 3 (S91/2s14) for t ≥40ms.
- Additionally hold down memory switch (S91/2s9) for t ≥40ms and release, then press corresponding position button on switch, memory location 1, 2, 3 (S91/2s14) within t ≤3s after releasing memory switch (S91/2s9)

The positions of the left electrically adjustable and heated outside mirror (M21/1) and right electrically adjustable and heated outside mirror (M21/2)are stored in the left front door control module (N69/1) or right front door control module (N69/2).

If the key-dependent memory position is activated in the instrument cluster (A1), the current mirror positions are stored with this key number when the transmitter key (A8/1) is removed
