GF82.95-P-2003QMA Emergency Call Actuation, Function

GF82.95-P-2003QMA Emergency Call Actuation, Function
- with CODE (359) TELE AID emergency call system
- TELE AID telediagnosis


Using the MB-Info and breakdown assistance button group (S93/6) either the roadside assistance call (symbol is a wrench) or the MB- Info call (symbol is the letter "i") is initiated by pressing in the corresponding direction. Pressing the MB-Info and breakdown assistance button group (S93/6) for longer than 0.5 s activates the system. The activated system is indicated by a flashing LED in the MB-Info and breakdown assistance button group (S93/6).

Irrespective of the request, the MB-Info and breakdown assistance button group (S93/6) is input by the emergency call system control unit (N123/4) via a discrete line. An SMS is sent automatically by the emergency call system control unit (N123/4). At the same time as the SMS is sent, a voice connection to the service center is established immediately.
