GF82.61-P-4000QMJ Destination-Oriented Navigation In Digitalized MAP Area, Function

GF82.61-P-4000QMJ Destination-Oriented Navigation In Digitalized Map Area, Function
- with CODE (498) Japan version


Destination-oriented navigation begins once the driver has entered destination, the position of the vehicle has been determined using the global positioning system (GPS), and the route has been calculated. The destination-oriented navigation uses images on the display of the COMAND operating, display and controller unit (A40/3) and the voice output of the navigation system to guide the driver to the desired destination. The driver can select one of the following map views in the destination-oriented navigation mode:
^ Destination-oriented navigation map
^ Route map (displays the entire route)
- 2D/3D switch (bird's-eye view)
- Split screen
- 2D/3D intersection zoom
- Lane recommendation
- Freeway information

The maps can be displayed in various sizes. For a better orientation on the screen, it is possible to select from 2 map orientations:
^ In the direction of travel
^ Facing north

Destination-oriented navigation within the digitized map area
During trips within the digitized map area, the following information calculated by the navigation processor of the COMAND operating, display and controller unit (A40/3) is available to the user:
^ Current position and route of vehicle on digitized map (graphically displayed)
^ List of routes
^ Distance from the destination and estimated time to arrival
^ Travel direction recommendation
^ Travel direction arrow
^ Name of current road
^ Name of the next road into which the vehicle should turn
^ Distance to next turning-off point (stated in length units or as a bar graph)
