GF82.85-P-2012QN Navigation Mode, Function

GF82.85-P-2012QN Navigation Mode, Function
- with CODE (525) MB Audio 50 APS radio


The location of the vehicle, as well as the direction and distance to the destination (after entering the destination) are determined with the aid of the navigation system. This system calculates the data required to reach the destination (navigation).
The navigation system can be activated by pressing the "NAV" button on the radio and navigation unit (A2/56).
The radio and navigation unit (A2/56) features an integrated navigation processor with a CD drive for digital data.
The user can enter the destination (menu-assisted) using the operating unit of the radio and navigation unit (A2/56). This destination entry is then processed by the navigation processor.

The user can enter the destination in the radio and navigation unit (A2/56) in the following ways:
^ Address input
^ Destination memory
^ Destination with map
^ Special destinations (e.g. train station, airport)
^ Travel guide
^ Last destinations

Predictive text input
While entering a destination the letters which are still missing are completed from an existing list of words. The predictive text input feature refers to the entry of the destination and street during navigation.

The "Special Destinations" menu is supplemented by the "Bypassing other Locations" and "National Destinations" submenus. The "National Destinations" menu is subdivided into an additional submenu.

Dynamic supplementation
The dynamic supplementation is realized when the destination is input manually. While entering a destination the letters which are still missing are completed from an existing list of words. The supplemented characters have a black background. The user can delete the characters one at a time (character by character).

Position finding
The navigation processor in the radio and navigation unit (A2/56) continually calculates the position of the vehicle using the following procedure:
^ Basic position finding (composite positioning)
^ Map-based position finding
^ GPS position finding

The navigation processor calculates the most likely position of the vehicle by constantly comparing the location results of these 3 methods.

Route calculation
The route is calculated in the navigation processor after destination input by the driver or automatically after a deviation from the proposed route.
With the dynamic navigation system, the route calculation is influenced automatically by incorporating traffic information. The calculated route is stored in the navigation processor.

Navigation
Navigation starts once the navigation processor has carried out the route calculation The navigation is supplemented by the voice output from the vehicle speakers.
