GF91.30-P-2006R Stop Ventilation Function

GF91.30-P-2006R Stop Ventilation Function
- with CODE (401) Front deluxe seats, including seat heating and seat ventilation

Function
Ventilation mode is stopped manually by operating the
^ Seat ventilation switch (S91/2s17)
^ Seat ventilation switch (S92/2s17)
^ Convenience closing using transmitter key (A8/1)

stopped.
It is also stopped automatically by the
^ left front seat adjustment control module with memory (N32/1)
^ right front seat adjustment control module with memory (N32/2) if:
^ Circ. 15R detects OFF (timer control runs for a further 5 min, if term. 15c is still "ON")
^ Undervoltage/overvoltage (≤ 11 V / ≤ 16 V) is detected (the timer control continues to run), the LEDs remain on.
^ the onboard power supply emergency running function has been activated (timer control continues).
